- Measuring range: R.T.~300℃
- Minimum digital display: 0.1℃
- Heating rates: 0.2 – 5.0 ℃/min
- Measurement methods: Automatic
Dropping-point and softening-point apparatus, MTP-DP1
الوصف
1.Designed according to ASTM D3461-97
2.Measure concentration polymerization degree, refractoriness of amorphousbody highly polymerized compound
3.Photoelectric test, temperature program control, LCD display, high precisionand stable performance
4.Widely used to component control and quality test of tar, asphalt, paraffin,resin, fats, rosin, lubricant, Vaseline, medical ointment, ointment, suppository, edible and grease
| Model | MTP-DP1 |
| Measuring range | Room temperature~300℃ |
| Minimum digital display | 0.1℃ |
| Linear heating rates | 0.2, 0.5, 1.0, 1.5, 2.0, 3.0, 4.0, 5.0 ℃/min |
| Furnace temperature | ≤200℃±0.5℃; >200℃ ±1℃ |
| The dimension of cup | Φ9.9mm (inside diameter), R4.6 ±0.1mm (bottom radius) |
| Hole size | Φ2.80mm (dropping-point), Φ6.35mm (softening-point), Φ5.00mm (user choose) |
| Ball | Lead ball (Φ3mm, 3.2±0.1g, according to ASTM) Steel ball (3.8”, according to GB2728-1988; 5/6” user choose) |
| Package Dimension (W*D*H) | 740*390*300mm |
| G.W. | 12.6kg |
